STCHD 360 Forestry Tiller – Heavy-Duty Soil Stabilizer & Stone Crusher for Tractors
The STCHD 360 is the ultimate solution for professional contractors and land managers who demand extreme performance from their equipment. Designed for high-horsepower tractors, this forestry tiller and stone crusher combines robust engineering, advanced rotor technology, and deep working depth to handle the most demanding land clearing, road building, and soil stabilization tasks.
Built with reinforced steel and premium-grade components, the STCHD 360 shreds rocks, mulches roots, and pulverizes soil up to 50 cm deep, creating a clean, level foundation for agricultural or construction purposes. Its hydraulically adjustable hood, dual transmission, and gearbox cooling system provide consistent power delivery and protection, even under extreme load.
Whether you’re stabilizing land for infrastructure or clearing forested plots, the STCHD 360 ensures maximum efficiency, reduced passes, and uncompromising results.
📊 Specifications Table:
Feature | Details |
---|---|
Working Width | 3600 mm (141.7 inches) |
Working Depth | Up to 50 cm (19.7 inches) |
Tractor Power Range | 300–500 HP |
Transmission Type | Dual Side Gear Drive with PTO Shaft |
Rotor Diameter | 675 mm with fixed teeth |
Number of Tools | Varies by configuration (approx. 72–88) |
Frame Material | Reinforced Wear-Resistant Steel |
Weight | Approx. 7,000–8,000 kg (model dependent) |
PTO Speed | 1000 rpm |
Applications | Soil Stabilization, Rock Crushing, Land Clearing |
⭐ 5 Key Features:
-
Extreme Duty Construction: Engineered with high-tensile steel for tackling rocks, roots, and dense soil.
-
Massive 141″ Working Width: Covers large areas quickly with precision and power.
-
Hydraulic Hood Control: Allows fine-tuning soil output and fragmentation for custom applications.
-
Advanced Cooling System: Keeps internal gears and PTO safe under heavy loads and high temperatures.
-
Fixed Teeth Rotor: Delivers consistent performance in even the toughest terrain, from forest paths to road prep.
